Informazioni Generali
Cantiere: ReutermannModello: CustomAnno di Costruzione: 2003
Tipo: Barche a velaTrattabile: SiVisibile a: Rosignano Marittimo
Prezzo: €: 650000
Descrizione
'windigo' bakewell-white 20.5m pocket maxi
specifications:
builder: windmill marine
design: bakewell-white yacht design ltd.
year launched: 2003
loa: 20.50m 67.25ft
lwl: 18.13m 59.48ft
bmax: 5.35m 17.22ft
draught min: 2.90m
max: 4.95m
displacement: 16,500kgs 36,366lbs
ballast: 7,500kgs 16,530lbs
sail area: 252.53m2 2287.66ft2
disp./length: 77.14
sa/disp: 33.35
hull and deck construction: carbon/kevlar/corecell/balsa/carbon chainplates
engineering: high modulus (nz) ltd.
rudder: carbon
keel: bisalloy 80/composite
engine: 150hp cummins 4bt3.9-m 4 cylinder diesel
spars: carbon by matrix masts nz
sails: kevlar doyles nz/norths
winches-competition : lewmar - pedestal x 2/electric main halyard
deck gear: lewmar
furler: harken
rudder bearings: jp3 self aligning
steering system: whitlock
manual hydraulics: navtec-compet.
lifting keel: custom hydraulic-compet.
anchor capstan: simpson lawrence hydraulic
water capacity: 300lt
diesel capacity: 145lt
electronics:
wind/performance: b&g hydra
chart plotter/gps: humminbird-geonav
2 x electric heads
upholstery: custom leather
timber veneer/trim american oak
stove/oven force: 10 lpg
refrigeration separate custom freezer and refrigeration
this yacht was developed as a fast day/weekend cruiser to be sailed by the family, but with the ability to be raced in coastal races with a full crew. the deck layout reflects this with major sail controls located within easy distance of the helm position and grinder pedestals providing plenty of centralised horsepower for sheeting. an electric winch is provided for hoisting the mainsail. a retractable bow prod allows easy downwind sailing with asymmetric spinnakers. the hydraulic lifting keel, anchor capstan and all engine controls are operated from the helm position.
the carbon rig is built with similar dimensions to a volvo 60 race yacht allowing the use of second-hand testing sails from syndicate inventories.
the structure has been engineered by high modulus (nz) ltd. in excess of the requirements of the american bureau of shipping guide for building and classing offshore racing yachts 1994 and whilst the design brief called for a daysailer this yacht is fully offshore capable.
---------------------------------------------------------------------------
inoltre
bandiera italiana
refitting 2010
tender e relativo motore
copertura fiocco
copertura randa
capottina offshore competition
seconda ancora
Scafo
Chiglia: DLunghezza F.T. (m): 21.0Baglio Massimo (m): 2.0
Immersione (m): 3.0Materiale Costruzione: NDCategoria CE: A
Disposizione interni
Bagni N. : 2Cuccette N. : 3Cabine N. :2
Strumentazione
Autopilota: SiPlotter: SiEcoscandaglio: Si
Strumenti Meteo: NoGPS: SiVHF: Si
Impianto 220v: Si
Motorizzazione
Motore: DTipo Motore: DieselPotenza (Hp): 150
Ore moto: 2500
Serbatoi
Carburante (lt) : 150
Acqua (lt) : 600
Piano velico
Tipo Vele : Randa Fiocco Genoa Tormentina Genaker
Superficie Velica (mq) : 400.00
